FS-1143 Sakura | Fuel Filter EFI 2330075100/ Z571 | FS1143

Overview

Sakura FS-1143 is a high-performance fuel filter designed for select Toyota models. The filter ensures the removal of particulate contaminants from fuel, safeguarding engine efficiency and longevity. Manufactured to exceed OEM specifications, this filter guarantees durability, optimum fit, and high filtration precision.

---

Specification

Bypass Valve: No
Anti Drain Back Valve: No
Net weight: 0.172 kg
Particle size filtration: 6.47 ?æm
Outer Diameter 1: 54 mm
Outer Diameter 2: 64.5 mm
Height 1: 123.5 mm
Height 2: 68 mm
Thread Size: M14X1.5
Filter Type: In-Line Filter

---

Technical

For maximum performance, replace the fuel filter according to Toyota's service recommendation. Ensure the engine is cool before installation. Check for leaks after installation.

---

Benefits

Ensures clean fuel supply to the engine, improving fuel efficiency and engine longevity. Reduces engine wear by filtering out particulate debris and contaminants. Direct OEM replacement simplifies installation, with no additional modifications required.

---

Install

1. Ensure vehicle engine is turned off and cool.
2. Locate the existing fuel filter within the fuel line.
3. Safely release any built-up pressure in the fuel system.
4. Remove the old filter and replace it with FS-1143.
5. Reconnect the fuel lines securely.
6. Check for any potential leaks before restarting the engine.

---

Fitment

TOYOTA
HILUX (1997-2002) RZN147, RZN152 81KW
HILUX (1998-2005) RZN154, RZN149 107KW
ARISTO (1997-2004) JZS160, JZS161
ALTEZZA (1998-2005) SXE10
HARRIER (1998-2003) MCU15

---

Cross Reference

Cross Reference
BOSCH
0 986450632

GENERAL MOTORS
88930455

Repco
RFF111

RYCO
Z571

Z593

SAKURA
FS-1143

FS-1143C

TOYOTA
2330074300

2330075100

2330075110

23300-74300

WESFIL
WZ571

FUEL FILTER EFI 2330075100/ Z571
TOYOTA 23300-74300
TOYOTA 23300-75100
TOYOTA 23300-75110

---

FAQ

Question: What Toyota models are compatible with this fuel filter?

The FS-1143 is compatible with Toyota HiLux, Aristo, Altezza, and Harrier models as specified.

Question: How often should the fuel filter be replaced?

Follow Toyota's recommended service intervals for replacing the fuel filter to maintain optimal performance.

Question: Does this fuel filter include a bypass valve?

No, the FS-1143 does not include a bypass valve.

Question: Can I install this filter myself?

Yes, the FS-1143 can be installed at home, but ensure all fuel system safety protocols are followed.

Question: Is the FS-1143 an original Toyota part?

No, it is a high-quality aftermarket part equivalent to OEM specifications.

---

HEIGHT

68

---

Box Quantity

50

---

Drain Plug

NO

---

By Pass / Valve

NO

---

Anti Drain Back

No

---

Absolute Micron

6.47

---

Thread

M14X1.5

---

Outlet

9

---

OUTER DIMENSION

54.000

---

Inventory Extended Details

The FS-1143 Sakura Fuel Filter provides superior filtration for your Toyota vehicle. It is an OEM replacement with the equivalent part numbers 20430785, RYCO Z571, and WESFIL WZ571. Manufactured by Phoenix Filters, the product is designed to offer excellent filtration performance, ensuring your engine runs smoothly without contaminants. Compatible with a range of Toyota vehicles including various HiLux models, the filter is built to fit seamlessly, requiring no modifications during installation.

---
